Scope AEA TT Disc & R9.T algorithm designed aero wheels debut at Tour de France time trial, with DSM on prototype Scott Plasma TT

Scope AEA Disc TT rear, R9.T deep front aero time trial wheels, 2022 Tour de France
1 Comment
Support us! Bikerumor may earn a small commission from affiliate links in this article. Learn More

Scope has a super-fast pairing of Algorithm Enhanced Aerodynamics time trial wheels with their new AEA Disc & R9.T, ready for today’s Tour de France départ. Developed in the wind tunnel and out on the road with DSM, this new wheel pairing promises a new benchmark in aerodynamic performance solo against the clock with modern wider tires and disc brakes.

And it looks like DSM are racing the wheels on an updated & unreleased Scott Plasma TT bike!

Scope AEA – Disc & R9.T aero TT wheels

Scope AEA Disc TT rear, R9.T deep front aero time trial wheels, rear
c. Scope

Interestingly, together with Eindhoven & Deft Universities of Technology and tire-maker Schwalbe, one of Scope’s big development partners for their Algorithm Enhanced Aerodynamics AEA projects is DSM. Technically not the Team DSM of pro cyclists, but the Dutch science & engineering company Royal DSM N.V. that sponsors the pro cycling team.

Scope AEA Disc TT rear, R9.T deep front aero time trial wheels

Scope is a “Supplier Partner” of Team DSM, but not one of their main sponsors, and the team most often races on Shimano wheels.

By the way, is that a next-generation Scott Plasma TT bike they are racing? It looks similar to the UCI-illegal triathlon Plasma, but we can’t find any more detail on a new TT version of the Plasma.
Update: Yes, it is. Check out the new Plasma TT here.

Scope AEA Disc TT rear, R9.T deep front aero time trial wheels, Tour de France 2022

But today for the Individual Time Trial that starts the 2022 Tour de France in Copenhagen today, the team did appear to be racing on these new Scope AEA wheels…

Scope AEA TT wheels, Team DSM Giro Donne
photo c. Team DSM

…like some of the DSM women may have done at the Giro Donne prologue, as well?

What’s new?

Scope AEA Disc TT rear, R9.T deep front aero time trial wheels, front tire

Scope introduced us to their algorithim-designed concept over basic CFD last spring with their latest all-road & road wheels. The general thinking is to start with the tire size & tire profile they want, then input the projected wind chareectueristics, and let the computer work back from that to create the most aero profile below the tire.

Scope AEA Disc TT rear, R9.T deep front aero time trial wheels, pair

Scope says the project used actual TT data collected from 2017-2020 at the 25 key Grand Tours & World Tour races by a “World Tour Team”. We’ll leave it up to you to guess which 3-letter team they are referring to. Five years in development, this time trial & triathlon aerodynamics project has now yielded a faster  Disc TT & deep-section R9.T wheel.

Scope AEA Disc TT rear, R9.T deep front aero time trial wheels, wind tunnel results

Scope says this is really just the first generation of AEA TT wheels developed from algorithm to wind tunnel to the road. But that’s not stopping them from making them available already, to pros and amateurs alike. This Mk.1 prototype setup has already proven to provide an 8% reduction in drag from the disc rear wheel and a 4% reduction in drag from the 88mm deep

Tech details

Scope AEA Disc TT rear aero time trial wheels
Scope AEA Disc rear wheel

The Scope AEA Disc is a tubeless carbon disc brake TT disc wheel with a 21mm hooked internal width and 28mm wide at the rim.

Scope AEA Disc TT rear aero time trial wheel profile

The disc wheel is built around an alloy Scope centerlock disc brake hub with 12mm thru-axle & ratchet internals, compatible with all Shimano, SRAM & Campagnolo groupsets. And it appears to have conventional Sapim Laser spokes inside its aero shell. The wheel spins on CeramicSpeed bearings and has a claimed​ ​weight of 1196g.

Scope AEA R9.T deep front aero time trial wheel
Scope AEA R9.T front wheel

The Scope AEA R9.T is front-specific, deep-section tubeless carbon TT wheel.

Scope AEA Disc TT rear R9T deep front aero time trial wheels, front hub detail

It has a narrower 19mm inner wdth, 26mm external, and an 88mm deep blunt aero rim profile featuring local reinforcement at the spokes. The wheel is built up with Scope’s straightpull centerlock hubs and Sapim CX-Ray spokes for a claimed wheel weight of 887g.

Scope AEA TT Mk1 Prototypes – Pricing & Availability

Scope AEA Disc TT rear R9T deep front aero time trial wheels, Scott Plasma complete

This first generation of Scope AEA Disc & R9.T wheels are both made by hand in the Netherlands, which means they are available in more limited numbers and are quite a bit more expensive than most Scope wheels. With that said, Scope is continuing to develop the pair, and expects to put them into larger scale production next year.

Scope AEA Disc TT rear R9T deep front aero time trial wheels, centerlock

The AEA Disc rear wheel sells for 2198€ with your choice of freehub to suit any modern drivetrain.  The R9.T sells for 998€ for the front wheel only. Both have no rider weight limit, with recommended tubeless tire width of 25mm rear, 28mm front. Contact Scope here to place an order.

ScopeCycling.com

Subscribe
Notify of
guest

This site uses Akismet to reduce spam. Learn how your comment data is processed.

1 Comment
Oldest
Newest Most Voted
Inline Feedbacks
View all comments
Greg
Greg
1 year ago

First, I have to believe that the “25mm rear, 28mm front” tire suggestion is backwards.
Second, shame on you for publishing a graph with no values on one axis.
