SOC13: Up Close with DVOs Mean Green Suspension Components, Plus Weights

Written by Saris Mercanti
17 Comments
Support us! Bikerumor may earn a small commission from affiliate links in this article. Learn More

DVO Fork no CTAFor the greater part of the past year, we’ve been closely following the progression of the new DVO downhill and coil rear shock. While we’ve covered the inception and technology in depth over the course of the past few months, Sea Otter was the first time we had the opportunity to see the goods in person.

Hop past the break for more….

DVO V10DVO is working with several top level athletes, including Cedric Gracia, to develop the next generation of suspension products. They’ve been working extensively with partners Gravity and Novatec to build several high end show bikes to product test and demo product.

DVO Preload Adjustment

DVO Rebound AdjAt the top of the fork, within easy reach, is the air cap and rebound adjustments.

DVO CrownsOriginally, DVO was experimenting with an unusual titanium collet system to tighten the crowns but high costs have kept the innovative design just out of the realm of practicality. Someday..

Different crowns will be available for both 26 and 650B wheels.

DVO Carbon Torsion Arc CTAThe Carbon Torsion Arc (CTA) is the not-so-secret ingredient DVO utilizes to compensate for the lack of stiffness inherent in inverted forks. In the future, we wouldn’t be surprised to see several arches available with different tunes to increase or decrease chassis stiffness based on rider weight and desired feel.

This Carbon Torsion Arc is one of the first DVO received from its overseas partners for testing. It’s been ravaged on countless shuttle laps across the jagged rocks of Mordor Southern Californias downhill trails and amazingly, it’s still in one piece.

DVO Low Speed Compression StackPeek under the fork to adjust the high and low speed compression or pull out the whole assembly to fiddle with the user serviceable damper. DVO plans on offering several tuning kits and a variety of educational videos on their website, so everyone from home mechanics to racers can fiddle to their hearts content.

Weights

DVO Shock and CTA Arc WeightThe DVO wrenches were busy installing forks on a few show and racer bikes and didn’t have any to weigh when we stopped in, but we did get a chance to put a preproduction shock and CTA on our scale.

Target Weight for the Emerald Fork is 2900 grams. Look for retail around $1,600 to $1,800 and availability towards the latter part of the year.

Show Bikes

DVO V10 Complete Show BikeDVO claims their Carbon Torsion Arc increases stiffness by 50% and they have been rigorously testing forks with and without the CTA.

Trek Session DVO Show BikeFor those who prefer the perceived slimming effect of black, DVO is also working on a murdered out version.
