Trek updates legendary 520 touring bike with new frame, fork, & more

569323 569324 569325 569326 569327 569328 569329 569330 569331 569332 569333 569334
23
Support us! Bikerumor may earn a small commission from affiliate links in this article. Learn More

If your idea of a touring bike involves less gravel and more panniers, take a look at the new Trek 520. Continuing the 520’s streak as the longest running model in Trek’s history, the 520 has been around in the line up since 1983. And while it still retains the original’s touring focus, the new bike has a few key upgrades to make it better than ever.

Trek updates legendary 520 touring bike with new frame, fork, & more Trek updates legendary 520 touring bike with new frame, fork, & more

Trek updates legendary 520 touring bike with new frame, fork, & more

In order to make it more comfortable and better handling, the frame and fork include a number of improvements. While the frame is still custom butted chromoly steel, the frame now has a larger diameter down tube for increased stiffness when fully loaded. The fork on the other hand has changed from steel to aluminum and includes Trek’s new ThruSkew captured quick release system. Trek describes it as a combination between a thru axle and quick release with the ability to remove the front wheel without having to remove the front cargo. It’s also 318g lighter than the previous steel fork.

The geometry has changed as well with a taller head tube that allows for a more upright position, a lower bottom bracket for better stability, and a longer wheelbase.

Trek updates legendary 520 touring bike with new frame, fork, & more

Built around 700c x 38mm tires, the frame and fork do have the capability of running up to 29 x 2.0″ tires if you want to get into more aggressive terrain. If not, there’s always the ability to run full coverage fenders around the stock tires.

Trek updates legendary 520 touring bike with new frame, fork, & more

Trek updates legendary 520 touring bike with new frame, fork, & more

Since this is a touring bike, the 520 comes equipped with full front and rear heavy duty racks capable of carrying 33lbs up front and 50lbs in the rear. Along with the three water bottle cage mounts, you should have plenty of gear carrying abilities. Between the gear and the rider, the bike carries a 300lb weight limit. The complete bike is said to weigh about 13.3kg.

Trek updates legendary 520 touring bike with new frame, fork, & more

The 520 also makes the jump from bar end to STI shifting with a Shimano Sora 3×9 wide range drivetrain. In order to handle the loads, the wheels are 36 spoke and tubeless ready – though to run tubeless, you’ll need to supply the rim strips, valves, sealant, and tubeless tires.

Available in red or grey, the complete bikes will be offered for $1,574.99 while a frameset will also be available for $639.99. Check out Trek’s website for more including the geometry numbers.

Subscribe
Notify of
guest

This site uses Akismet to reduce spam. Learn how your comment data is processed.

23 Comments
Oldest
Newest Most Voted
Inline Feedbacks
View all comments
Dockboy
Dockboy
4 years ago

650b? The bb drop seems okay for it.

tamaleslayer
tamaleslayer
4 years ago

The aluminum fork sounds awful. Why the departure from a steel fork ?

Dinger
Dinger
4 years ago
Reply to  tamaleslayer

“It’s also 318g lighter than the previous steel fork.”

Seraph
Seraph
4 years ago
Reply to  Dinger

Then why not carbon?

John
John
4 years ago
Reply to  Seraph

@Seraph: A carbon fork would *not* be a good choice for a loaded touring bike with front panniers.

Dinger
Dinger
4 years ago
Reply to  Seraph

I’m sure carbon could be engineered to work just fine, but once you add the in-mold mounts and all the strength necessary for touring use, I wonder if it would wind up being that much lighter? It’d certainly be a lot more expensive.

Gregory Tillery
Gregory Tillery
4 years ago
Reply to  Dinger

This doesn’t exactly seem like the kinda bike you’re counting grams on.

Steven Kovalenko
4 years ago

That’s a lot of versatile, capable bike for not a lot of money. Nice.

JBikes
JBikes
4 years ago

Agree. At least put it on the frameset if cost is a driver and charge more.

Bokito
Bokito
4 years ago

300lb (136kg) max load: does that include the bike? If so, this is a deal breaker for a (expedition) touring bike. If the racks are aluminium, you probably want to replace them with steel ones.
For the rest it ticks many boxes.

Chadder
Chadder
4 years ago
Reply to  Bokito

Weight limit does not include the bike weight.

It is about the rider and cargo for this bike.

JBikes
JBikes
4 years ago
Reply to  Chadder

No, all trek weight limits include the bike as well as rider and cargo.
I’m not sure why its really its really rated the way it is though. Brakes? Trek’s lightest emonda slr carries the same weight limit, as do most of their bikes.

And I’m not sure the 520 was ever a “expedition class” tourer.

John
John
4 years ago
Reply to  JBikes

My late ‘80s Trek 520 had ~30000 miles on it when I finally retired it. Loaded touring, all around commuter, rain or shine. It was every bit an “expedition class” tourer for its time.

JBikes
JBikes
4 years ago
Reply to  John

I just view “expedition class” as something built specifically for extremely long, self supported tours in areas of the world with poor or no roads…i.e. 26″ mtb wheels, possibly knobbies.
520 always just seems like a great “normal” long distance road tourer/everything bike.

BMX
BMX
4 years ago

Totally agree with you, the only fork I ever cracked was alloy. Due to flex alloy forks go through under braking and vibration the alloy tends to work harden then crack. Steel doesn’t fatigue the same. Carbon forks don’t really fatigue at all. And I know some people will have a different take on this but that my experience – not theory.

Dinger
Dinger
4 years ago
Reply to  BMX

All of that comes down to engineering and use case. I’ve only ever seen carbon forks break, though I ride them on all of my road bikes, because I trust where they came from.

gringo
gringo
4 years ago

38c tires on deep dish rims while loaded down does not sound like too much fun to me. Every other bike segment has proven the benefits of wider rubber. Specialized also nailed it with the big rubber and wide rims on Sequoia.

Looks OK otherwise.

Dinger
Dinger
4 years ago
Reply to  gringo

38’s are nice for road touring. It’s got plenty of clearance for more, so an easy change.

Rick Kasbow
Rick Kasbow
4 years ago

I just bought one in diablo red and put veto orange Zeppelin fenders on, gorgeous. I have it parked next to my K1600 GT & R1200GSA. I am now ready for retirement.

IvIv
IvIv
4 years ago

Are there any information about the “ThruSkew”-System? Looks to me like a “normal” Through-Axle with inlets for a standard 9mm QR-Axle:

comment image

IvIv
IvIv
4 years ago
Reply to  IvIv

…eh… I mean: “Looks to me like a “normal” Through-Axle-Dropout”…. sry.
