Ursus Weaves Copper Brake Track to Carbon Rims, Introduces Mountain Bike Wheels

Written by Tyler Benedict
21 Comments
Support us! Bikerumor may earn a small commission from affiliate links in this article. Learn More

2014 Ursus C25 and C50 carbon fiber road bike wheels use a woven copper brake track

Italian wheel manufacturer Ursus has turned to metallurgy to combat heat related braking issues on their carbon rims.

The 2014 Ursus C25 and C50 carbon clincher wheels get a new 1mm thick copper weave in the brake track that they say drastically reduces braking temperatures. It’s bonded in during construction, so it shouldn’t wear off. That’s combined with their HTG high temp resin to dramatically reduce heat buildup. They’re saying braking temps can run as high as 300-400 degrees C, and these reduce it down to 70-100 degrees C.

Weights are 600g front /750g rear (C25) and 695g/845g (C50). Retail is $2,400 per pair. Both are 20mm wide at the outside, and they’re 25mm and 50mm deep respectively.

Closeups of the copper and the actual production finish, plus their new mountain bike wheels, below…

2014 Ursus C25 and C50 carbon fiber road bike wheels use a woven copper brake track

A close up view of the copper weave.

2014 Ursus C25 and C50 carbon fiber road bike wheels use a woven copper brake track

On production models, it won’t be quite so coppery looking. Here’s a finished wheel…

2014 Ursus C25 and C50 carbon fiber road bike wheels use a woven copper brake track

…and a close up of the production brake track.

2014-Ursus-Diablo-29er-mountain-bike-wheels

They’ve also added mountain bikes wheels to the line. The top model is the carbon rimmed Diablo, which comes in 27.5″ and 29er. Rims are reinforced unidirectional fibers that are 25mm wide and 20mm deep. They’re built with Sapim spokes using Ursus’ SLN (Self Locking Nipple) system that places nylon bushings around the nipple to prevent binding or loosening. They come in at 615g F/783g R for the 27.5″ hoops and 650g F/825g R for 29ers.

2014-Ursus-Viper-650B-mountain-bike-wheels

Below that are two alloy models below it called Viper and Spark, both with anodized black aluminum rims. The Viper (above) comes in all three wheel sizes with an 18mm deep asymmetric rim, offsetting the spoke bed for more even tension. They’re built with the SLN nipple system, but use different rim widths and spokes for the larger two wheel sizes. The 26″ is a bit lower end with Sapim Force spokes and a 22mm wide rim…and it’s a bit heavier for it The 27.5″ and 29er get CX-Ray spokes and a wider 25mm rim. Weights are 730g F/855g R (26″), 650g F/818g R (27.5″) and 685g F/815g R (29er).

2014-Ursus-Spark-650B-mountain-bike-wheels

At the low end are the Spark, a basic alloy wheel. It also comes in all three wheel sizes, uses SLN and has a 23mm wide/18mm deep rim. Weights are 900g F/1140g R (26″), 925g F/1165g R (27.5″) and 975g F/1195g R (29er).

Ursus.it
Tyler Benedict
11,295 articles

Tyler Benedict is the Founder of Bikerumor.com, where he’s been writing about the latest bikes, components, and cycling technology for almost two decades. Prior to that, Tyler launched and built multiple sports nutrition brands and consumer goods companies, mostly as an excuse to travel and ride in new places.

Based in North Carolina, Tyler also loves the Vanlife & family adventure travel and is always on the lookout for the next shiny new part and off-grid adventure.

Subscribe
Notify of
guest


This site uses Akismet to reduce spam. Learn how your comment data is processed.

21 Comments
Oldest
Newest Most Voted
Inline Feedbacks
View all comments
SYJ
SYJ
11 years ago

So how exactly are a $2400 pair of 600+ gram 25mm deep Ursus copper/carbon rims superior to a $160 pair of 450 gram 25mm deep H+ Son Archetypes?

0
Reply
Echo
Echo
11 years ago

Whats weight for the whole wheel not just the rim

0
Reply
ChrisW
ChrisW
11 years ago

Those are WHEEL weights, not rim weights.

0
Reply
Eyal
Eyal
11 years ago

This is really exciting! I ride carbon tubulars. But I would consider these clinchers before I would consider disc brakes. Besides, Lightweight, Zipp, Reynolds and Enve now have resins to cope with heat dissipation.

0
Reply
SYJ
SYJ
11 years ago

Ah. That makes a bit more sense

0
Reply
Alex K
Alex K
11 years ago

With all the development moving towards disc brakes, I don’t quite understand all the work being put into rim brakes.

0
Reply
MaLóL
MaLóL
11 years ago

disc brakes is about marketing, rim brakes is about performance and racing. so simple.

0
Reply
MulletRacer
MulletRacer
11 years ago

Malol, the same was said for MTBs 15 years ago. Now, you wouldnt have your mtb any other way.

The manufacturers are going to shove it down our throats. There is no point in resisting.

Jump on the band wagon. Embrace it!

0
Reply
Adam12
Adam12
11 years ago

Alex K: The UCI has not approved disc breaks for road bikes as of yet so that is why there is so much attention to money spent on improving rim brakes.

MaLóL: I will disagree with you. From personal experience, disc brakes perform much better in wet and sloppy conditions than the rim brakes do. In normal, dry conditions, your argument may be valid.

0
Reply
Rain
Rain
11 years ago

Soon as manufacturers eliminate road rim brakes the size of wheels will NEED to be changed.

What reason will be used to sell it?

0
Reply
david
david
11 years ago

I hope they make an option to have the copper visible if that’s feasible from a performance standpoint. It’d look great on a black frame.

0
Reply
Mindless
Mindless
11 years ago

@Malol: It is exactly the other way around. Reliable day to day performance of disk brakes vs. useless gram counting for show.

0
Reply
K11
K11
11 years ago

copper brake track design. pointless with disc brake technology evolving in road applications.

0
Reply
THAT GUY
THAT GUY
11 years ago

Solution looking for a problem. Rim brakes already provide too much braking performance.

0
Reply
alvis
alvis
11 years ago

So if the brakes run cooler where does the energy go? If they don’t get hot they don’t stop. Simple physics.

0
Reply
Reynard2ki
Reynard2ki
11 years ago

LOL. More disc brake for road bikes chatter on Bike Rumor. I wonder how many of the advocates for disc brakes on road bikes have much of a racing resume beyond cat 4, because I haven’t heard a single person in my local scene pining for them. And I live in the Midwest, where we get a lot of terrible weather. A lot of talk about tubeless, nothing about disc brakes.

0
Reply
Gillis
Gillis
11 years ago

Reynard, your “scene” is not the world. Perhaps you should move somewhere with real mountains and rain. In places like the PNW its not unheard of for commuters to burn through an aluminum rim in a year. And it’s not unheard of to burn through a set of pads racing in a downpour.

Aris, brakes don’t work from heat, they work on friction, which heat is a product of. Simple physics.

One of the long standing problems with carbon is that it retains too much heat and can compromise the resin (and glue in the case of tubulars). Which is the high temp resin is even mentioned.

0
Reply
Reynard2ki
Reynard2ki
11 years ago

Right, and your scene isn’t the world, either. One size fits all doesn’t work in clothing, and doesn’t work in bikes. It seems like the industry is bound to push this on everyone, regardless of need. I can’t see them taking hold for a while since there’s no UCi approval and you’ll be totally hosed by neutral support at crits and road races. I can’t wait to see a dude who needs a wheel and support has nothing with a disc.

0
Reply
Gillis
Gillis
11 years ago

All I’m saying is that there are enough places in the world to justify their use. And from what I’ve heard, UCI is looking at the issue and it is likely only a few years away from approval.

The industry is pushing it, but there are a lot people who want it too, even if they aren’t where you live.

Not sure why you’d take pleasure someone else’s misfortune though, that’s pretty low.

And earlier I meant Alivs, not Aris.

0
Reply
Psi Squared
Psi Squared
11 years ago

@alvis: there is an optimum temperature range for brake pads, and it’s pretty low. It is certainly well below the high temperatures that can be generated on CF rims, temperatures that can reach glass transition temps.

Where does the energy go? The energy is distributed through the copper to a much larger area and is lost much more quickly through convection. The thermal conductivity of copper is roughly twice that of aluminum (from 0-250°C), but that larger conductivity is offset somewhat by the smaller volume and surface area of the copper mesh in these wheels compared to that of an aluminum rim.

0
Reply
Psi Squared
Psi Squared
11 years ago

Reynard2ki, you need to take off the binary blinders. Yes, there is no doubt the fraction of road bikes sold with disc brakes is going to go up significantly, maybe even dramatically, over the next few years. That does not mean that all bikes will have them. There will likely be a market for rim brakes for a very long time to come.

Are disc brakes going to make it into the road racing scene and even the pro peloton? Yup. It’s going to happen no matter your snark.

0
