Monstrous new Diamondback Haanjo Carbon adventure bike will tackle any epic ride

2017 Diamondback Haanjo EXP Carbon drop bar 275 adventure gravel bike

Diamondback has just upped the game by taking their versatile alloy Haanjo gravel bike platform, which comes in drop and flat bar iterations, and giving it a shapely new carbon frame with a bad ass 27.5 x 2.1 option spec’d with a mountain taming 3×9 Shimano drivetrain. Don’t worry, 2×11 700c builds are also offered…but, just look at this thing!

Pairing easy to maintain TRP Spyre mechanical disc brakes, bar end shifters and HED Tomcat wheels, the 2017 Diamondback Haanjo EXP Carbon is ready for any epic backcountry ride. And perhaps the best part (besides the sick army green paint job) is the price…

2017 Diamondback Haanjo EXP Carbon drop bar 275 adventure gravel bike

The Haanjo Carbon series gets DB’s relaxed “Endurance” geometry, which means a slightly slacker head angle, 45mm fork offset and 430mm chainstays.

2017 Diamondback Haanjo EXP Carbon drop bar 275 adventure gravel bike

2017 Diamondback Haanjo EXP Carbon drop bar 275 adventure gravel bike

An external threaded bottom bracket adds to the ease of use of this package.

2017 Diamondback Haanjo EXP Carbon drop bar 275 adventure gravel bike

Thru axles front and rear, an XT cassette rear derailleur paired with Dura-Ace bar end shifters, Tektro brake levers, and Schwalbe tires round out the package for just $2,300.

DB rider Eric Porter took the EXP model for a little 150 mile jaunt from Reno, NV, to California, and made a video to show it off.

2017-Diamondback-Haanjo-Trail-Carbon-700c-adventure-gravel-road-bike

At the top of the Haanjo Carbon lineup is the Trail model, which gets Shimano Ultegra derailleurs with Shimano’s non-series hydraulic disc brakes and levers. Those are paired with SRAM Rival wide axle cranks with 50/34 chainrings. It, along with the Haanjo Comp Carbon below, both use 700×40 Schwalbe G-One tires on HED Tomcat alloy wheels with 21mm inside width rims. Retail for the Trail model is $3,100.

Note the rounded seatstays and flattened seat tube, all designed to give the bike a bit of cush over the rough stuff.

2017-Diamondback-Haanjo-Comp-Carbon-650b-adventure-gravel-road-bike

The Haanjo Comp comes in at $2,500 with FSA cranks and BB, Shimano 105 shifters/derailleurs/cassette and TRP Spyre mechanical discs. All of the carbon frames have full rack and fender mounts.

2017-Diamondback-Haanjo-Tero-700c-drop-bar-gravel-road-bike

If you hadn’t seen them (we hadn’t), the 6061-T6 butted alloy models were released for 2016 and include five models, two with flat bars. Above is the $900 Tero with super shallow drop bars and a steel fork, and…

2017-Diamondback-Haanjo-Carbon-700c-flat-bar-gravel-road-bike

…the standard flat bar Haanjo with tapered alloy fork for $1,100. Check out the complete line up on their website.

Diamondback.com
