CX Pro Bike Check: Cervelo’s new Cyclocross World Cup bike is… an Aspero gravel bike!

CX Pro Bike Check, carbon Cervelo Aspero gravel bike raced at the Cyclocross World Cup as a cross race bike by Joris Nieuwenhuis
11 Comments
Support us! Bikerumor may earn a small commission from affiliate links in this article. Learn More

If you want more clarity of the difference between a top-level cyclocross race bike and a race-ready gravel bike, you won’t find it from Cervélo. Over the weekend of UCI World Cup racing, we spotted Team Sunweb rider Joris Nieuwenhuis racing the carbon Cervelo Aspero gravel bike head-to-head with the world’s best cyclocross racers. So how does a gravel bike fare at the CX World Cup?

Cervélo Áspero gravel bike’s double life as a cyclocross bike

So what was it that separates a gravel bike from a cyclocross bike again? Generally we look at gravel bikes fitting larger diameter tires, having more relaxed & stable geometry, and more comfort & adventure focused versatility.

But it all is in a manner of degrees. As we’ve seen gravel bikes start to differentiate themselves into fast gravel racing, all-around gravel, adventure gravel, and even bikepacking sub-genres, some modern gravel bikes aren’t so far away from some cross bikes.

So what does it take to race a gravel bike at the Cyclocross World Cup?

CX Pro Bike Check, carbon Cervelo Aspero gravel bike raced at the Cyclocross World Cup as a cross race bike by Joris Nieuwenhuis

In fact, those gravel changes vs. cyclocross were already the advantages that cyclocross bikes had over traditional road bikes. Cervelo is clearly planted in the more racy “aero is everything” side of bikes they build, and they explicitly said the new Aspero is meant to “haul ass, not cargo“.

Cyclocross conversion – tech details

CX Pro Bike Check, carbon Cervelo Aspero gravel bike raced at the Cyclocross World Cup as a cross race bike by Joris Nieuwenhuis

So to turn a gravel bike into a cross race bike for their one cross-racing pro, Team Sunweb built up an Aspero with a cross-proven Shimano Dura-Ace Di2 R9170 double groupset with pro-only 46/39 gearing, 140mm rear/160mm front rotors, Dura-Ace carbon tubular wheels and hard-to-beat Dugast 33mm tubulars, the latest XTR pedals, and PRO Vibe cockpit.

CX Pro Bike Check, carbon Cervelo Aspero gravel bike raced at the Cyclocross World Cup as a cross race bike by Joris Nieuwenhuis

Curiously, there’s what appears to be a two-bolt FSA zero offset carbon seatpost, instead of the PRO variant that has a rotating head that is probably not very well suited for cyclocross remounts.

Another odd thing about the Aspero (and one I heard a different team’s mechanic grumble about in the Depo), is that the front thru-axle threads on from the driveside, while the rear threads on from the non-driveside. In a sport where fast work in the pits can be crucial to success, the disparity was apparently a sore point.

From a slightly different perspective, there has been discussion that removing levers from the left side of the bike is beneficial, since most cross racers dismount to the left. But along that line, the rear should probably be flipped too?

Cervelo Aspero’s adjustable geometry?

CX Pro Bike Check, carbon Cervelo Aspero gravel bike raced at the Cyclocross World Cup as a cross race bike by Joris Nieuwenhuis

A closer look at that front axle also reminds us that the Aspero has a flip chip at the dropout designed to affect the bike’s handling depending on wheel & tire size used. Note that Nieuwenhuis has his axle in the forward position.

Cervelo actually specs the Aspero with the Trail Mixer dropout in the rearward position for smaller diameter tire setups (650b x 47mm or 700c x 32mm) for a bit more Trail to balance the inherent quick steering with a more stable ride.

CX Pro Bike Check, carbon Cervelo Aspero gravel bike raced at the Cyclocross World Cup as a cross race bike by Joris Nieuwenhuis

The forward position was designed for larger diameter tires (~700c x 40mm) to get less Trail overcoming the slower handling of the bigger tire and return some of that quicker steering. So, it’s really no surprise that Nieuwenhuis runs his smaller UCI-legal cross tires with the Trail Mixer in the less Trail setting to get both the more maneuverability of the lighter, smaller diameter tire & even faster steering to get around the tight cyclocross corners.

Team Sunweb’s custom cyclocross solutions

CX Pro Bike Check, carbon Cervelo Aspero gravel bike raced at the Cyclocross World Cup as a cross race bike by Joris Nieuwenhuis

One complication of the gravel geometry though, is its 76mm of bottom bracket drop. More than 1cm lower than Mathieu van der Poel’s race winning Inflite, which would make riding the deep mud ruts and steep off-cambers that you actually find on almost every World Cup cyclocross course even more difficult to navigate without pedal strikes. (That’s also 1cm higher that Nieuwenhuis would have to bunny-hop if he was planning to ride the barriers instead of running them.)

CX Pro Bike Check, carbon Cervelo Aspero gravel bike raced at the Cyclocross World Cup as a cross race bike by Joris Nieuwenhuis
courtesy of Team Sunweb (this photo only)

But… Team Sunweb has a solution. Since the Aspero has a large 46mm shell diameter BBright bottom bracket shell that fits a 30mm axle with a standard bearing, the team was able to fit an eccentric bottom bracket for Nieuwenhuis that fits the 24mm Dura-Ace axle (like the Wheels Manufacturing eccentric for BB30/PF30). That means they could effectively reduce the frame’s BB drop by 6mm or more, getting it back closer to a typical cross standard dimension.

CX Pro Bike Check, carbon Cervelo Aspero gravel bike raced at the Cyclocross World Cup as a cross race bike by Joris Nieuwenhuis

The team also says some additional Dyneema fibers were added to the down tube, in what appears to just be two thin strips to protect the upper part of the tube against impacting barriers or other hard objects in case of some major crash.

CX Pro Bike Check, carbon Cervelo Aspero gravel bike raced at the Cyclocross World Cup as a cross race bike by Joris Nieuwenhuis

So how did the Aspero fare under the Dutch road WorldTour rider and past U23 CX World champ. You see Joris Nieuwenhuis racing with number four, which means he was the fourth highest ranked UCI rider on The Netherlands’ team, and he’s ranked 14th overall in UCI CX and now 12th in the World Cup.

Nieuwenhuis finished 11th in Tabor, a solid cyclocross position for someone racing a gravel bike against the best riders in the world (and faster than every crosser not from The Netherlands or Belgium to boot!)

Cervelo.com

Subscribe
Notify of
guest

This site uses Akismet to reduce spam. Learn how your comment data is processed.

11 Comments
Oldest
Newest Most Voted
Inline Feedbacks
View all comments
mtbinavl
mtbinavl
4 years ago

In what world is the argument that “removing levers from the left side of the bike is beneficial, since most cross racers dismount to the left” or keeping the levers on the same side, is more important that keeping your hand away from the rotor (where your dirty hand can contaminate the rotor or the rotor has any chance of potentially cutting your hand)?

Steve Hindman
Steve Hindman
4 years ago
Reply to  mtbinavl

Yes, on my QR cross bike with disc brakes I purposefully put the skewer in from the drive side so that I avoid getting my hands near the rotor.

Thinsport Kelsey
Thinsport Kelsey
4 years ago

Last year I bought an S works gravel bike for women and I use it as a cyclocross and gravel bike. I’m a very petite woman (98lbs and 5’1) and I mainly wanted to use this bike for cyclocross. Unfortunately, all the cyclecross bikes just didn’t feel right and I fell in love with the S works gravel bike for women. The way it feels and performs is so much better than my old cyclocross bike. I don’t think I’ll ever go back to a cyclecross bike unless it feels like my gravel S works.

Greg
Greg
4 years ago

Less rake for smaller wheels is to keep the trail the same/similar/consistent, not to account for any perceived “quickness”. Most people using 650 wheels and up with the biggest tires they can squeeze in. How is that quicker handling?

Brad Comis (@BradComis)
Reply to  Greg

Lower trail means less force at the bars for a given displacement of the front wheel. That rules holds true regardless of tire size. The note in the article is saying that when running larger diameter 700×35+ tires its possible to configure the fork with less trail (more offset) to make the steering feel closer to what you would have with smaller outer diameter tires. Really you can just select whichever one floats your boat. There is a pretty wide range of trail figures that work for drop bar bikes.

Heffe
Heffe
4 years ago

A quick glance at the head and seat tube angles shows that the Aspero doesn’t have typical gravel bike geometry by any means, so asking ‘how does a gravel bike fare in cx’ isn’t really applicable for this bike, except for the bottom bracket drop.

Dinger
Dinger
4 years ago
Reply to  Heffe

I’d argue that the Apero’s numbers are typical of more of the mainstream gravel bikes (Diverge, Checkpoint, Revolt, etc.). Sure, there are slack, raked out bikes running 650b and other things, but the bikes that sell in large numbers are closer to warmed over CX bikes because these make for the most versatility from pavement (where lots of them spend most of their time) to dirt.

Velo Kitty
Velo Kitty
4 years ago

BBRight is the future! lol Why would Cervelo saddle an otherwise good frame with their doo-doo BBRight bottom bracket “standard” instead of spec’ing the frame with BB386EVO?

Dan Reese
Dan Reese
4 years ago

Wasn’t the only reason he was on the Aspero that his bikes got stolen? I think he had custom Cervelo CX bikes that were stolen in the week before the race.

Steve Hindman
Steve Hindman
4 years ago
Reply to  Dan Reese

According to Team SunWeb’s post on FB, he does normally ride Asperos, but you are correct that his race rigs were stolen right before the event.

dang3rtown
4 years ago
Reply to  Dan Reese

UCI Rule 1.3.006
Technical innovations
Bicycles and their accessories Equipment shall be of a type that is sold for use by anyone practicing cycling as a sport.

You can’t run a custom made bike in a UCI race. Closest you could come would be a prototype that will soon be made available.
